Introduction

Hey guys! Ever feel like you're stumbling in the dark when trying to figure out what parameters Google Apps Script (GAS) is passing to your event handlers? You're not alone! The GAS documentation can sometimes feel like a cryptic puzzle, leaving us developers scratching our heads. But fear not! In this article, we're going to dive deep into how we can uncover this hidden information at runtime. We'll explore a simple yet powerful technique to peek behind the curtain and see exactly what's being passed to our functions. So, buckle up, and let's get ready to discover the secrets of GAS event handlers!

The Challenge of Insufficient Documentation

As developers, we often rely heavily on documentation to understand how a particular framework or language works. When the documentation is clear and comprehensive, it makes our lives significantly easier. However, when the documentation is lacking, especially in critical areas like event handling, it can lead to frustration and wasted time. With Google Apps Script, the documentation for event parameters is often sparse, leaving developers guessing or resorting to trial and error. This is where the ability to dynamically discover information at runtime becomes invaluable. By using techniques to inspect the parameters being passed to our event handlers, we can gain a deeper understanding of the system and write more robust and efficient code. In the following sections, we'll explore a practical approach to achieve this, empowering you to tackle even the most poorly documented aspects of GAS with confidence. We'll cover how to use simple logging and inspection techniques to reveal the hidden data structures and values that GAS is passing around, ultimately making you a more effective and resourceful GAS developer.

Why Runtime Discovery Matters

In the world of web application development, understanding how your application behaves at runtime is crucial. Runtime discovery, or the ability to uncover information about your application's state and behavior while it's running, is a powerful tool in a developer's arsenal. This is particularly true when dealing with frameworks or libraries that have incomplete or unclear documentation. In the context of Google Apps Script, runtime discovery allows us to peek under the hood and see what's happening when events are triggered, forms are submitted, or other user interactions occur. By inspecting the parameters that are passed to event handlers, we can learn about the structure of the data, the types of values being passed, and any other relevant context information. This knowledge is essential for building robust and reliable web applications. For example, imagine you're building a web form using Google Apps Script and you need to process the data submitted by the user. The event handler for the form submission will receive a set of parameters, but the exact structure of these parameters might not be immediately clear from the documentation. By using runtime discovery techniques, such as logging the parameters to the console or inspecting them in a debugger, you can quickly understand how the data is organized and how to access the values you need. This not only saves you time and frustration but also allows you to write more efficient and maintainable code. Furthermore, runtime discovery is not just about overcoming documentation gaps; it's also a valuable skill for debugging and troubleshooting issues in your application. By observing the behavior of your application at runtime, you can identify unexpected data patterns, pinpoint the source of errors, and develop effective solutions. So, mastering the art of runtime discovery is a key step in becoming a proficient Google Apps Script developer.

A Trivial Example: Unveiling Event Handler Parameters

Let's dive into a trivial example to illustrate how we can discover information about the parameters passed to event handlers in Google Apps Script. Suppose we have a simple web application, and we want to understand what parameters are being passed to the doGet(e) function, which is the entry point for handling HTTP GET requests. This is a common scenario when building web apps or custom user interfaces within Google Workspace.

Setting Up the Script

First, let's create a new Google Apps Script project. You can do this by going to script.google.com and starting a new project. Once you have a new project open, you can paste the following code into the script editor:

function doGet(e) {
 Logger.log(JSON.stringify(e));
 return HtmlService.createHtmlOutput("<h1>Hello, World!</h1>");
}

In this snippet, we define the doGet(e) function, which is the standard function that handles HTTP GET requests in Google Apps Script web applications. Inside the function, we use Logger.log(JSON.stringify(e)) to log the e parameter to the execution log. The JSON.stringify() function is crucial here because it converts the complex JavaScript object e into a JSON string, which can be easily read and understood in the logs. We also return a simple HTML output to display “Hello, World!” in the browser.

Deploying the Web App

Next, we need to deploy this script as a web application. To do this, follow these steps:

  1. Click on “Deploy” in the top right corner of the script editor.
  2. Select “New deployment”.
  3. Under “Select type”, choose “Web app”.
  4. Configure the settings:
    • Description: Add a description (e.g., “Test web app”).
    • Execute as: Select “Me” (or “User accessing the web app” depending on your needs).
    • Who has access: Choose “Anyone” (for testing purposes) or a more restrictive option for production.
  5. Click “Deploy”.
  6. Authorize the script when prompted.

Once deployed, you'll get a web app URL. Open this URL in your browser.

Inspecting the Logs

Now, go back to the Google Apps Script editor and click on “Executions” on the left sidebar. You should see the execution of your doGet(e) function. Click on the execution to view the details, and you'll find the logged JSON string. This string represents the e parameter, which contains information about the HTTP request. By examining this JSON, you can discover the parameters being passed, such as query parameters, headers, and other request details. This simple example demonstrates the power of using Logger.log(JSON.stringify(e)) to uncover the structure and content of event handler parameters in Google Apps Script. This technique can be applied to various event handlers, allowing you to understand the context and data available to your scripts at runtime.

Decoding the Parameter Object

So, you've used Logger.log(JSON.stringify(e)) and you've got a big, gnarly JSON string staring back at you. Now what? This section is all about breaking down that JSON and understanding what it means. Don't worry, it's not as scary as it looks! We'll walk through the common elements you'll find in these parameter objects and how to make sense of them.

Understanding the Structure

The first thing to realize is that the e parameter is a JavaScript object, and the JSON string we logged is simply a serialized representation of that object. This object contains key-value pairs, where the keys are strings and the values can be strings, numbers, booleans, arrays, or even other objects. The structure of this object varies depending on the event that triggered the handler. For example, the e object for a doGet(e) function (handling HTTP GET requests) will be different from the e object for a form submission event or a spreadsheet edit event.

Common Elements in Event Parameter Objects

While the specific properties of the e object will vary, there are some common elements you'll often encounter:

  • parameters: This is a crucial property, especially for web applications. It's an object that contains the query parameters passed in the URL. For instance, if your URL is https://script.google.com/a/macros/example.com/s/AKfy.../exec?name=John&age=30, the e.parameters object will look something like {"name": ["John"], "age": ["30"]}. Notice that the values are arrays, even if there's only one value.
  • queryString: This property contains the entire query string part of the URL (e.g., name=John&age=30).
  • parameter: This is a flattened version of parameters. Instead of having values as arrays, it directly maps parameter names to their first values (e.g., {"name": "John", "age": "30"}).
  • contextPath: This property provides the base URL path for the script.
  • content: This property is often present in events that involve content, such as form submissions. It contains the data submitted in the request body.
  • headers: This property (if present) contains the HTTP headers of the request.
  • authMode: This property indicates the authorization mode of the script execution.
  • user: This property (if present) contains information about the user who triggered the event.
  • values: This property is commonly found in spreadsheet events and contains the values of the cells that were edited.

Example: Decoding a doGet(e) Parameter

Let's say you log the e parameter for a doGet(e) request and you see the following JSON:

{
 "parameter": {
 "name": "Alice",
 "age": "25"
 },
 "parameters": {
 "name": [
 "Alice"
 ],
 "age": [
 "25"
 ]
 },
 "contextPath": "/macros/s/AKfy.../exec",
 "queryString": "name=Alice&age=25",
 "contentLength": -1
}

From this, we can infer the following:

  • The URL likely had query parameters name and age.
  • e.parameter.name gives us `
